Lee Precision Case Length Gage and Shellholder 6.5x52 Carcano 90043
The Case Length Gage and Shellholder is the assembly consisting of the length gage and the dedicated shellholder with which Lee Precision trims cases to size and squares the case mouth. This unit works on the 6.5x52 Carcano: the trim length is determined by the gage geometry, meaning it does not depend on operator adjustments or readings and remains identical for the entire batch of cases.
The case is held by the shellholder while the cutting tool rests on the gage: the cut stops automatically when the case reaches the specified length, which for the 6.5x52 Carcano is between 2.047 and 2.067 inches. The assembly acts as a go/no-go gage: if the case is not cut, it means it is already within limits. Lee specifies a tolerance of +.000/-.015 inches for these units. Trimming is performed after full-length resizing, once the case has stretched: returning it to size prevents the case mouth from bottoming out in the chamber and maintains a consistent crimp. The case mouth is squared perpendicular to the case axis, a condition that affects bullet concentricity. The system is entirely mechanical and requires no calibration or maintenance.
Main features
- Length gage and shellholder dedicated to the 6.5x52 Carcano
- Trim length between 2.047 and 2.067 inches
- Mechanical stop: length repeatable across the entire batch of cases
- Lee tolerance +.000/-.015 inches
- Works as a go/no-go gage: if the case is not cut, it is already to size
- Squares the case mouth perpendicular to the axis
- Requires no adjustments or calibration
Recommended use
The gage must be paired with a Lee cutting tool sold separately: Cutter and Lock Stud 90110, Cutter with Ball Grip and Lock Stud 90275, or the Deluxe Case Conditioning Combo 92160, which includes a cutter and lock stud, chamfer tool, primer pocket cleaner, and power grip shell holder. The Cutter and Lock Stud is universal; one is sufficient for all cartridges with a bullet diameter smaller than .475 inches, and it can be used by hand or with an electric drill. After trimming, it is recommended to chamfer and deburr the case mouth with the Lee Chamfer Tool 90109.
Package contents
- Case Length Gage 6.5x52 Carcano
- Dedicated shellholder
- Not included: cutting tool (Cutter and Lock Stud 90110 or equivalent)
Manufacturer code: 90043
